Kite Optics Ibis ED Binoculars
ERGONOMIC DESIGN
Love at first sight. The IBIS ED brings the open-bridge design to the KITE range. The possiblity to wrap your entire hand around one of the barrels while keeping your index finger on the focus wheel, gives you a unique comfort and allows viewing and operating of the instrument with one hand only. The binocular barrels are slim, but still featre a sufficiently thick rubber armor with texture to provide you maximum grip. The metal twist-up eyecups are removable, allowing the user to easily clean them or replace them by new ones if necessary. The ED/HD optical system provides a briliant and sharp image from centre to edge. The color tone is perfectly natural for accurate determination.
- Lightweight ergonomic open hinge design
- Textured rubber for optimal grip
- sharp from centre to edge
- ED/HD optical system
- KITE PERMAVISION
- KITE PERMARESIST
- 4 stage removable aluminum twist-up eyecups
- KITE MHR Advance + coating
- Fully waterproof and nitrogen filled
- 30y warranty
- including lens covers, straps and pouch
7x42 | 8x42 |
10x42 |
8.5x50 |
10x50 |
12x50 | |
Magnification | 7 | 8 |
10 |
8.5 |
10 |
12 |
Objective lens diameter (mm) | 42 |
42 |
42 | 50 |
50 | 50 |
Exit Pupil (mm) | 6 |
5.25 |
4.2 |
5.88 |
5 |
4.16 |
Min. close focus (m) | 1.4 |
1.4 |
1.4 |
2.6 |
2.6 |
2.6 |
Field of view (m/1000m) | 128 |
126 |
114 |
102 |
102 |
99 |
Field of view (degrees) | 7.3 |
7.2 |
6.5 |
5.85 |
5.85 |
5.7 |
Eye relief (mm) | 19.5 |
17 |
17 |
17.5 |
19 |
16.4 |
Interpupillary distance (mm) | 73-55 | 73-55 | 73-55 | 73-55 | 73-55 | 73-55 |
Height (mm) | 148 |
148 |
148 |
175 |
175 |
175 |
Max width (mm) | 126 |
126 |
126 |
132 |
132 |
132 |
Min width folded (mm) | 109 |
109 |
109 |
116 |
116 |
116 |
Weight (g) | 725 |
745 |
760 |
868 |
887 |
902 |
Twilight factor | 17.1 |
18.3 |
20.5 |
20.6 |
22.4 |
24.5 |
Dioptric compensation (+/-) | 3 | 3 | 3 | 3 | 3 | 3 |
Waterproof | yes | yes | yes | yes | yes | yes |
Gas Filled | yes | yes | yes | yes | yes | yes |
Functional temperature | -25°/55° | -25°/55° | -25°/55° | -25°/55° | -25°/55° | -25°/55° |
Light transmission (%) | 90 |
91 |
91 |
90 |
90 |
89 |
Warranty (years)* | 30 | 30 | 30 | 30 | 30 | 30 |
